| Application |
Optimally and flexibly used in the warping of various kinds of nylon, fiber, cotton yarn, etc. |
| Beam Specification |
Diameter of the application beam is below 400 mm, diameter of inside hole is 17 mm or 20 mm, inner length is 255 mm. We also specially make the machine according to customer requirements. |
| Speed Adjustment |
Frequency control: 0 ~ 350 r/min (Line speed: 0 ~ 390 m/min) |
| Set Length |
Use the counter to set any warp length according to the requirement. |
| Width & Density Adjustment |
Adopt 4 pieces of W-reed; adjust width and the left and right device randomly. |
| Motor |
2 HP / 4P / 380V 3 Phase |
